SPECIFICATIONS
-
FRAME
All New Unidirectional Carbon Fiber Front Triangle, Series 4 Alloy Rear End, 29” Wheels, 150mm Travel MultiTrac Suspension Platform, Internal Dropper Post and Rear Derailleur Routing, Chainstay Mounted Post Mount Disc Brake, 148x12mm Boost Thru-Axle, 73mm Threaded BB w/ ISCG05 Tabs
-
FORK
Fox 38 Performance Elite, 160mm Travel, 29" , 110x15mm Boost Kabolt Thru-Axle, 44mm Offset, Integrated Fox Fender
-
REAR SHOCK
Fox Float DPX2, Performance, EVOL Air Spring, 3 Position Compression Adjustment, Rebound Adjustment, 205x65mm, Trunnion Upper Mount, 25mmxM8 Lower Mount
-
RIMS
Marin, Double Wall Alloy, 29mm Inner, Welded Joint, Disc Specific, 32H, Tubeless Compatible
-
HUB REAR
Shimano HB-MT510B, 148x12mm, Centerlock, Microspline Freehub Body
-
HUB FRONT
Shimano HF-MT410B, 110x15mm, Centerlock
-
SPOKE
14g Black Stainless Steel
-
TIRES
Front: Maxxis Assegai 29x2.5”, MAXX TERRA, EXO+, Tubeless Compatible; Rear: Maxxis Assegai 29x2.5”, MAXX GRIP, DoubleDown, Tubeless Compatible
-
DERAILLEUR REAR
Shimano XT 12-Speed, SGS
-
DERAILLEUR FRONT
-
-
SHIFT LEVER
Shimano SLX 12-Speed, I-Spec EV
-
CRANKSET
FSA Gradient, Modular 1x, 32T Direct Mount Chainring, MegaTooth Technology, Mego EXO Spindle, Boost Spacing
-
BOTTOM BRACKET
MEGAEVO BB, 73mm BSA Threaded
-
CHAIN
KMC X-12 Silver and Black
-
CASSETTE
Shimano SLX M7100 Cassette, 12-Speed, 10-51T
-
BRAKE FRONT
Shimano SLX, 4-Piston Hydraulic Disc, 203mm Rotor
-
BRAKE REAR
Shimano SLX, 4-Piston Hydraulic Disc, 180mm Rotor
-
BRAKE LEVERS
Shimano SLX Hydraulic, I-Spec EV
-
HANDLEBAR
Race Face Affect R 35, 35mm Clamp, 780mm Width, 20mm Rise, 5º Up, 8º Back
-
STEM
Race Face Affect R 35, 50mm
-
GRIPS
Marin Single Clamp Locking
-
HEADSET
FSA No 57, Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
-
SEATPOST
X-Fusion Manic, Size S 125mm Travel, Size M and L 150mm Travel, Size XL 170mm Travel, 30.9mm, Shimano MT500 1x Lever, I-Spec EV
-
SADDLE
Marin Trail Speed Concept Pro
-
PEDALS
Not Included
-
EXTRAS
Bolt-On Thru-Axle, Downtube Protector
Specifications, pricing, and availability are subject to change without notice.
GEOMETRY
S | M | L | XL | |
---|---|---|---|---|
STACK | 619 | 628 | 632 | 643 |
REACH | 430 | 455 | 480 | 515 |
HEADTUBE ANGLE | 63.5° | 63.5° | 63.5° | 63.5° |
HEADTUBE LENGTH | 100 | 110 | 115 | 130 |
SEATTUBE ANGLE | 78° | 78° | 78° | 78° |
SEATTUBE LENGTH | 390 | 400 | 425 | 430 |
TOPTUBE EFFECTIVE | 561.7 | 589 | 615 | 652 |
BB HEIGHT | 342 | 342 | 342 | 342 |
BB DROP | 35 | 35 | 35 | 35 |
CHAINSTAY | 430 | 430 | 430 | 430 |
WHEELBASE | 1199 | 1229 | 1256 | 1297 |
STANDOVER HEIGHT | 690 | 694 | 695 | 698 |
FORK OFFSET | 44 | 44 | 44 | 44 |
SEATPOST DIAMETER | 30.9 | 30.9 | 30.9 | 30.9 |
HANDLEBAR WIDTH | 780 | 780 | 780 | 780 |
STEM LENGTH | 50 | 50 | 50 | 50 |
CRANK LENGTH | 170 | 170 | 170 | 170 |
All lengths in millimeters
